Model no
414

SIGMA 20mm F1.4 DG DN | Art

Admirably balanced performance and size

• Highest optical performance on a new level
• Designed for perfect results even in the most demanding conditions
• Front filter thread (φ82mm)
• Super multi-layer coating
• Dust-and splash-resistant structure
• Designed to minimize flare and ghosting
• Rear Filter Holder
• Lens heater retainer
• Available in Sony E-mount and L-mount

As low as €1.049,00

Highest optical performance on a new level

The SIGMA 20mm F1.4 DG DN | Art delivers exceptionally detailed results that easily satisfy the high demands of professional photography and other high-end applications.

With 17 glass elements arranged in 15 groups, including two SLD, three aspherical glass elements and the largest class double-sided aspherical glass element in SIGMA’s history, the 20mm F1.4 DG DN | Art rigorously suppresses various optical aberrations such as sagittal coma flare or image distortion to produce highly-detailed images with exceptional sharpness and accuracy from the center to the furthest corners, allowing photographers to make use of the entire field of view afforded by its ultra-wide viewing angle.

This ultimate astrophotography lens is the culmination of the unparalleled manufacturing technology of SIGMA’s sole production base in Aizu, Japan, as well as the company’s know-how and experience with large-aperture wide-angle lenses, such as the SIGMA 20mm F1.4 DG HSM | Art, the SIGMA 14mm F1.8 DG HSM | Art and the SIGMA 14-24mm F2.8 DG DN | Art.

enige productiebasis in Aizu, Japan.

Designed for perfect results even in the most demanding conditions
SIGMA’s outstanding design and high-precision manufacturing capabilities made it possible to equip the SIGMA 20mm F1.4 DG DN | Art with a front filter thread despite its very large F1.4 aperture and 20mm ultra-wide viewing angle.

The lens also comes with a rear filter holder, allowing photographers the freedom to combine multiplefilters to suit a huge variety of shooting situations for near-unlimited creative potential at an ultra-wide viewing angle—for example, using a front filter to reduce light pollution and a softening filter on the rear to take impressive photographs of nightly landscapes with star-filled skies.

The new MFL (Manual Focus Lock) switch to turn off the focus ring makes it easier to concentrate on the shoot without worrying about accidentally changing the focusing distance. Further, the lens also equips a lens heater retainer, meaning that lens heaters used to prevent internal condensation as the temperature drops on longer night shoots will stay securely attached to the barrel without protruding into the image and causing unsightly vignetting.

With its brilliantoptical power and its full range of useful features despite its compact and lightweight body, the SIGMA 20mm F1.4 DG DN | Art is the ultimate choice when photographing the night sky.

Superb build quality and usability with uncompromising attention to detail
Its dust-and splash-resistant structure*1and the water-and oil-repellent coatingon the front glass element make the SIGMA 20mm F1.4 DG DN | Art safe to use during longer outdoor shoots, especially during the night.

Thoughtful features such as a focus mode switch, a customizable AFL*2button, and an aperture ring lock switch enhance the lens usability. An aperture ring click switch can be used to turn the aperture ring click on and off, allowing photographers to enjoy the sound and feel of the click, as well as smooth aperture operation during video recording.

The robust body is built from a combination of aluminum and Thermally Stable Composite (TSC), giving it a sleek finish, and the included petal-shaped lens hood is equipped with a lock mechanism to keep the hood securely fastened to the lens, and the rubberized grip area makes attaching and removing the hood a quick and easy process.

*1 Although this construction allows the lens to be used in lightrain, it is not the same as being waterproof.
*2 Only on compatible cameras. Available functions may vary depending on the camera used.

Specifications
More Information
Product LinesArt
Construction17 elements in 15 groups
Lens TypeWide Angle
Sensor SizeFull Frame
Angle of view94.5°
Number of diaphragm blades11
Minimum aperture16
Minimum focusing distance23cm
Maximum magnification ratio1:6.1
Dimensions (diameter x length)φ87.8mm × 111.2mm
Dimensions (diameter x length)

L-mount
Sony E-mount

φ87.8mm × 111.2mm
φ87.8mm × 113.2mm

Weight (g)630
Weight (g)

L-mount
Sony E-mount

635 gram
630 gram

Filter diameter82mm
Edition number22
EAN

L-mount
Sony E-mount

0085126414696
0085126414658

* All figures calculated by L-Mount. Note: The L-Mount Trademark is a registered Trademark of Leica Camera AG. About Product Name: Product name includes "DG" when the lens is designed to deliver the ultimate in performance on cameras with full-frame sensors, and "DN" when the lens design is optimized for mirrorless cameras with the short flange focal length.
Lens Construction
Geometrical MTF Chart
Diffraction MTF Chart
